B324R

DURABLE FLAT HEAD RESIN

Engineered to provide high durability in thermal transfer printing.

B324 is a UL approved multi-purpose resin ribbon designed to work with flat head technology printers in demanding industrial conditions. The most durable ribbon in the range, this high performance resin is designed for the most demanding applications.

B324’s durable performance characteristics include its ability to withstand repeated exposure to chemicals such as isopropanol and brake fluid, as well as high temperature resistance, making it an ideal choice for demanding applications in a wide range of high end market sectors.

Applications

We understand that each industry and every application has unique requirements for thermal transfer printing, and that the ribbon needs to have certain functionality and durability characteristics for that market sector.
ITW Thermal Films has the right Flexible, Durable and/or Extreme thermal transfer ribbon for your application with distinctive needs of each market we serve. Click on the applications below to find your perfect ribbon!

B324 is suitable for all applications listed below and many more.

ITW RESIN FLAT HEAD RIBBONS

  • ENERGY
  • ABRASION RESISTANCE
  • HEAT RESISTANCE
  • SOLVENT RESISTANCE
  • LABEL ADAPTABILITY
  • PRINT DENSITY

CHARACTERISTICS

Low printhead energy

Abrasion resistance

Scratch resistance

Print flexibility

High density print

Chemical resistance to common agents

Chemical resistance to hazardous chemicals

High speed

Wide working windows

Anti-static PrintheadSaver® coating

ITWThermalRibbon

PROPERTIES

Color

Red

Optical Density (Reflective)

> 0.60

Optical Density (Transmission)

> 0.20

Ink Melting Point

110°C

Carrier

4.5μm Polyester film

Thickness

< 9.0 μm

SUBSTRATES

Papers

Synthetics

Polyester, Polyethylene, Polypropylene, PVC

This information is the best currently available. The results should only be regarded as a general guide to material properties and not as a guarantee. Please contact us for further detail.

Shinemark

COMPLETE RIBBON SELECTION

B200

FLEXIBLE

Wax

B220

DURABLE

Wax

B121

FLEXIBLE

Wax Resin Flat Head

B128

DURABLE

Wax Resin Flat Head

B120

MAGIC

Wax Resin Flat Head

B120R

MAGIC

Wax Resin Flat Head

B325

FLEXIBLE

Resin Flat Head

B325W

FLEXIBLE

Resin Flat Head

B324

DURABLE

Resin Flat Head

B324R

DURABLE

Resin Flat Head

B112

FLEXIBLE

Wax Resin Near Edge

P110

HIGH SPEED

Wax Resin Near Edge

P110W

HIGH SPEED

Wax Resin Near Edge

P114

4.0 MICRON PET

Wax Resin Near Edge

P311

FLEXIBLE

Resin Near Edge

D330

TEXTILE

Textile

Contact us to find out more about our B324 Ribbon

REQUEST A SAMPLE
