P114
FLEXIBLE NEAR EDGE WAX RESIN
Engineered for efficiencey on near edge and corner edge technology online coders
A Near Edge wax/resin offering at least 20% longer length roll capabilities at even lower energy settings. Specifically designed for in-line packaging applications and print and apply where speed is critical. This extremely flexible, operator friendly ribbon, consistently produces all of the characteristics required in high volume, just in time printing at an optimum performance level. Combining the ability of less downtime and speeds upto 800mm/s this is the go to market leading coding ribbon.
Applications
We understand that each industry and every application has unique requirements for thermal transfer printing, and that the ribbon needs to have certain functionality and durability characteristics for that market sector.
ITW Thermal Films has the right Flexible, Durable and/or Extreme thermal transfer ribbon for your application with distinctive needs of each market we serve. Click on the applications below to find your perfect ribbon!
P114 is suitable for all applications listed below and many more.
- ENERGY
- ABRASION RESISTANCE
- HEAT RESISTANCE
- SOLVENT RESISTANCE
- LABEL ADAPTABILITY
- PRINT DENSITY
CHARACTERISTICS
Abrasion resistance
Scratch resistance
Print flexibility
High density print
Chemical resistance to common agents
Chemical resistance to hazardous chemicals
High speed
Wide working windows
Anti-static PrintheadSaver® coating
PROPERTIES
Color
Black
Optical Density (Reflective)
> 1.50
Optical Density (Transmission)
> 0.80
Ink Melting Point
70°C
Carrier
4.0μm Polyester film
Thickness
< 7.5 μm
SUBSTRATES
Papers
Uncoated, Coated, Card
Synthetics
Polyester, Polyethylene, Polypropylene, PVC
This information is the best currently available. The results should only be regarded as a general guide to material properties and not as a guarantee. Please contact us for further detail.
